SSD 2.5“ Samsung 870 QVO 1TB SATA3 560MB/s
Application - Client PCs
Rated Capacity - 1,000 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor - 2.5 inch
Interface - SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD) - 100 X 69.85 X 6.8 (mm)
Weight - Approx. 46.0g Weight
Storage Memory - Samsung V-NAND 4bit MLC
Controller - Samsung MKX Controller
Cache Memory - Samsung 1 GB Low Power DDR4 SDRAM
Special Feature
TRIM Support - TRIM Supported
S.M.A.R.T Support - S.M.A.R.T Supported
GC (Garbage Collection) - Auto Garbage Collection Algorithm
Encryption Support - AES 256-bit Encryption (Class 0),TCG/Opal, IEEE1667 (Encrypted drive)
WWN Support - World Wide Name supported
Device Sleep Mode Support - Yes
Performance
Sequential Read - Up to 560 MB/s Sequential Read * Performance may vary based on system hardware & configuration
Sequential Write - Up to 530 MB/s Sequential Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD32) - Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD32) - Up to 88,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Read (4KB, QD1)
Up to 11,000 IOPS Random Read * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Random Write (4KB, QD1) - Up to 35,000 IOPS Random Write * Performance may vary based on system hardware & configuration ** Measured with Intelligent TurboWrite technology being activated
Environment
Average Power Consumption (system level) - Average: 2.2 W *Maximum: 4.0 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle) - Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage - 5V ± 5% Allowable voltage
Reliability (MTBF) - 1.5 Million Hours Reliability (MTBF)
Operating Temperature - 0 - 70 ? Operating Temperature
Shock - 1,500 G & 0.5 ms (Half sine)
Software
Management SW
Magician Software for SSD management
SSD 2.5“ Samsung 860 Evo 250GB SATA3 MZ76E250B
General Feature
Application - Client PCs
Capacity - 250 GB (1 GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor - 2.5 inch
Interface - SATA 6 Gb/s Interface, compatible with SATA 3 Gb/s & SATA 1.5 Gb/s interface
Dimension (WxHxD) - 100 X 69.85 X 6.8 (mm)
Weight - Max 50.0g Weight
NAND Type - Samsung V-NAND 3bit MLC
Controller - Samsung MJX Controller
Cache Memory - Samsung 512 MB Low Power DDR4 SDRAM
Special Feature
TRIM Support - TRIM Supported
S.M.A.R.T Support - S.M.A.R.T Supported
GC (Garbage Collection) - Auto Garbage Collection Algorithm
Encryption Support - AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support - World Wide Name supported
Device Sleep Mode Support - Yes
Performance
Sequential Read - Up to 550 MB/s Sequential Read * Performance may vary based on system hardware & configuration
Sequential Write - Up to 520 MB/s Sequential Write * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32) - Up to 98,000 IOPS Random Read * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32) - Up to 90,000 IOPS Random Write * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1) - Up to 10,000 IOPS Random Read * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1) - Up to 42,000 IOPS Random Write * Performance may vary based on system hardware & configuration
Environment
Power Consumption - *Average: 2.2 W*Maximum: 4.0 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
Reliability (MTBF) - 1.5 Million Hours Reliability (MTBF)
Operating Temperature - 0 - 70 ? Operating Temperature
Shock - 1,500 G & 0.5 ms (Half sine)
Software
Management SW - Magician Software for SSD management
