MB Gigabyte H370 HD3 (rev. 1.0)
CPU
Support for 9th and 8th Generation Intel® Core™ i7 processors/Intel® Core™ i5 processors/Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1151 package
L3 cache varies with CPU
(Please refer “CPU Support List“ for more information.)
Chipset
Intel® H370 Express Chipset
Memory
4 x DDR4 DIMM sockets supporting up to 64 GB of system memory
Dual channel memory architecture
Support for DDR4 2666/2400/2133 MHz memory modules
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules
* To support 2666 MHz or XMP memory, you must install an 8th Generation Intel® Core™ i7/i5 processor.
(Please refer “Memory Support List“ for more information.)
Onboard Graphics
Integrated Graphics Processor-Intel® HD Graphics support:
1 x D-Sub port, supporting a maximum resolution of 1920x1200@60 Hz
1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
* The DVI-D port does not support D-Sub connection by adapter.
1 x HDMI port, supporting a maximum resolution of 4096x2160@30 Hz
* Support for HDMI 1.4 version and HDCP 2.2.
Support for up to 3 displays at the same time
Maximum shared memory of 1 GB
Actual support may vary by CPU.
Audio
Realtek® ALC887 codec
High Definition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
LAN
Intel® GbE LAN chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x4 (PCIEX4)
4 x PCI Express x1 slot
(All of the PCI Express slots conform to PCI Express 3.0 standard.)
1 x PCI slot
1 x M.2 Socket 1 connector for an Intel® CNVi wireless module only (CNVI)
Multi-Graphics Technology
Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies
Storage Interface
Chipset:
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 PCIe x4/x2 SSD support) (M2M_32G)
1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe x2 SSD support) (M2P_16G)
6 x SATA 6Gb/s connectors
Support for RAID 0, RAID 1, RAID 5, and RAID 10
* Refer to “1-7 Internal Connectors,“ for the installation notices for the M.2 and SATA connectors.
Intel® Optane™ Memory Ready
USB
Chipset:
1 x USB Type-C™ port on the back panel, with USB 3.1 Gen 1 support
1 x USB 3.1 Gen 2 Type-A port (red) on the back panel
6 x USB 3.1 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
* The CNVi connector shares bandwidth with the F_USB2 header. When a Wi-Fi module is populated in the CNVi connector, one of the USB 2.0/1.1 ports routed to the F_USB2 header becomes unavailable.
Internal I/O Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x CPU fan header
3 x system fan headers
1 x RGB LED strip header
6 x SATA 6Gb/s connectors
2 x M.2 Socket 3 connectors
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 3.1 Gen 1 header
2 x USB 2.0/1.1 headers
1 x Thunderbolt™ add-in card connector
1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
1 x parallel port header
1 x serial port header
1 x Clear CMOS jumper
Back Panel Connectors
1 x PS/2 keyboard/mouse port
1 x D-Sub port
1 x DVI-D port
1 x HDMI port
1 x USB Type-C™ port, with USB 3.1 Gen 1 support
1 x USB 3.1 Gen 2 Type-A port (red)
4 x USB 3.1 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks
I/O Controller
iTE® I/O Controller Chip
H/W Monitoring
Voltage detection
Temperature detection
Fan speed detection
Overheating warning
Fan fail warning
Fan speed control
* Whether the fan speed control function is supported will depend on the cooler you install.
BIOS
2 x 128 Mbit flash
Use of licensed AMI UEFI BIOS
Support for DualBIOS™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Support for APP Center
* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
3D OSD
@BIOS
AutoGreen
Cloud Station
EasyTune
Easy RAID
Fast Boot
Game Boost
ON/OFF Charge
Platform Power Management
RGB Fusion
Smart Backup
Smart Keyboard
Smart TimeLock
Smart HUD
System Information Viewer
USB Blocker
V-Tuner
Support for Q-Flash
Support for Xpress Install
Bundled Software
Norton® Internet Security (OEM version)
cFosSpeed
Operating System
Support for Windows 10 64-bit
Form Factor
ATX Form Factor; 30.5cm x 22.5cm
Remark
Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors` website or 3rd party website.
Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
ASUS PRIME B450M-A II
ASUS PRIME B450M-A II
AMD AM4 Socket AMD Ryzen 2nd Generation/Ryzen with Radeon Vega Graphics/Athlon with Radeon Vega Graphics/Ryzen 1st Generation Processors
AMD Ryzen 2nd Generation/Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics/ Ryzen 1st Generation Processors
4 x DIMM
Max. 32GB
DDR4 3466(O.C.)/3200(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666/2400/2133 MHz Un-buffered Memory
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU
Integrated Graphics in the AMD Ryzen with Radeon Vega Graphics/ Athlon with Radeon Vega Graphics Processors
Total supports 1 x M.2 slot(s) and 6 x SATA 6Gb/s ports
Multi-VGA output support : HDMI/DVI-D/D-Sub ports
Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz
Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
Supports D-sub with max. resolution 1920 x 1200 @ 60 Hz
Expansion slots: AMD Ryzen 2nd
Generation/ Ryzen 1st Generation Processors: 1 x PCIe 3.0/2.0 x16 (x16 mode)
AMD Ryzen with Radeon Vega Graphics Processor: 1 x PCIe 3.0/2.0 x16 (x8 mode) *1
AMD Athlon with Radeon Vega Graphics Processors: 1 x PCIe 3.0/2.0 x16 (max at x4 mode)
AMD B450 chipset: 2 x PCIe 2.0 x1
Realtek RTL8111H
1 x Gigabit LAN Controller(s)
ASUS LAN Guard
Back I/O Ports: 1 x PS/2 keyboard/mouse combo port(s)
1 x DVI-D
1 x D-Sub
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.2 Gen 2 (teal blue) (2 x Type-A)
4 x USB 3.2 Gen 1 (blue) Type-A
3 x Audio jack(s)
1 x BIOS FlashBack Button(s)
90MB15Z0-M0EAY0
ASUS PRIME A320M-K
AMD AM4 Socket for AMD Ryzen™/7th Generation A-series/Athlon™ Processors, Supports CPU up to 8 cores, Memory: AMD Ryzen™ Processors 2 x DIMM, Max. 32GB, DDR4 3200(O.C.)/2933(O.C.)/2666/2400/2133 MHz ECC and non-ECC, Un-buffered Memory, Dual Channel Memory Architecture, Graphics: Integrated AMD Radeon™ R Series Graphics in the 7th Generation A-Series APU *1, Multi-VGA output support : HDMI/RGB ports,- Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz, Maximum shared memory of 2048 MB, Expansion slots: AMD Ryzen™ Processors 1 x PCIe 3.0/2.0 x16 (x16 mode), AMD 7th Generation A-series/Athlon™ Processors, 1 x PCIe 3.0/2.0 x16 (x8 mode), AMD A320 chipset, 2 x PCIe 2.0 x1, LAN: Realtek® RTL8111H, 1 x Gigabit LAN Controller(s), Audio: Realtek® ALC887 8-Channel High Definition Audio CODEC, Back IO ports: 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x D-Sub, 1 x HDMI, 1 x LAN (RJ45) port(s), 4 x USB 3.1 Gen 1 (blue), 2 x USB 2.0, 3 x Audio jack(s)
MB MSI MAG B550M MORTAR RYZEN DDR4-4400+MHz 2.5G LAN USB3.2 DP/HDMI
MAG B550M MORTAR
Support for 3rd Gen AMD Ryzen™ Processors and future AMD Ryzen™ processors with BIOS update
Supports DDR4 Memory, up to 4400+(OC) MHz
Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 Gen 2
Premium Thermal Solution: Extended Heatsink Design with additional choke thermal pad rated for 7W/mk and PCB with 2oz thickened copper are built for high performance system and non-stop gaming experience.
Enhanced Power Design: 8+2+1 Duet Rail Power system, Digital PWM, Core Boost, DDR4 Boost.
2.5G LAN with LAN Manager: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection.
Pre-installed I/O Shielding: Better EMI protection and more convenience for installation.
Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience.
Multi-GPU: With Steel Armor PCI-E slots. Supports 2-Way AMD Crossfire™
SOCKET: AM4
CPU (MAX SUPPORT): RYZEN 9
CHIPSET: AMD B550 Chipset
DDR4 MEMORY: 4400(OC)/ 4300(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3300(OC)/ 3200(JEDEC)/ 3000(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHz
MEMORY CHANNEL: Dual
DIMM SLOTS: 4
MAX MEMORY (GB): 128
PCI-E X16: 2
PCI-E X1: 2
SATAIII: 6
M.2 SLOT: 2
RAID: 0/1/10
LAN: 1x Realtek® RTL8125B 2.5G LAN
USB 3.2 PORTS (FRONT): 1(Gen 1, Type C), 2(Gen 1, Type A)
USB 3.2 PORTS (REAR): 1(Gen 2, Type C), 1(Gen 2, Type A), 2(Gen 1, Type A)
USB 2.0 PORTS (FRONT): 4
USB 2.0 PORTS (REAR): 2
AUDIO PORTS (REAR): 5+ Optical S/PDIF (Realtek® ALC1200 Codec)
DISPLAYPORT: 1
HDMI: 1
DIRECTX: 12
FORM FACTOR: Micro-ATX
CROSSFIRE: Y
OPERATING system: Support for Windows® 10 64-bit
ASUS TUF GAMING Z590-PLUS
ASUS PRIME H310M-R 2.0
• Intel Socket 1151 for 8th and 9th Generation Core Processors • Chipset: Intel H310 • Memory: 2 x DIMM • Max. 32GB • DDR4 2666/2400/2133 MHz Non-ECC • Un-buffered Memory *Dual Channel Memory Architecture• Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support : HDMI/DVI-D/D-Sub ports
• Supports HDMI with max. resolution 4096 x 2304 @24Hz
• Supports DVI-D with max. resolution 1920 x 1200 @60Hz
• Supports D-Sub with max. resolution 1920 x 1200 @60Hz
• 1 x PCIe 3.0/2.0 x16 (x16 mode)
• 1 x PCIe 3.0/2.0
• 4 x SATA 6Gb/s port(s)
• LAN: Realtek RTL8111H
• 1 x Gigabit LAN
• Back I/O ports: 1 x PS/2 keyboard (purple)
• 1 x PS/2 mouse port (green)
• 1 x HDMI
• 1 x DVI-D
• 1 x D-Sub
• 1 x LAN (RJ45) port(s)
• 2 x USB 3.1 Gen 1
• 2 x USB 2.0
• 3 x Audio jack(s)
• MicroATX
• 90MB0YL0-M0ECY0
ASUS PRIME H310-PLUS
• Intel® Socket 1151 for 8th Generation Core™ Processors • Chipset: Intel® H310 • Memory: 2 x DIMM • Max. 32GB • DDR4 2666/2400/2133 MHz Non-ECC • Un-buffered Memory *Dual Channel Memory Architecture • Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/D-Sub ports
• 1 x PCIe 3.0/2.0 x16 (x16 mode)
• 2 x PCIe 3.0/2.0 x1
• 3 x PCI
• 1 x M.2 Socket 3
• with M key
• type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
• 4 x SATA 6Gb/s port(s)
• LAN: Intel® I219V
• 1 x Gigabit LAN
• Back I/O ports: 1 x PS/2 keyboard/mouse combo port(s)
• 1 x HDMI
• 1 x D-Sub
• 1 x LAN (RJ45) port(s)
• 2 x USB 3.1 Gen 1 (blue) Type-A
• up to 5Gbps
• 2 x USB 2.0
• 1 x COM port(s)
• 1 x LPT port
• 3 x Audio jack(s)
ASUS PRIME B360-PLUS
Intel® Socket 1151 for 8th Generation Core™ Processors, Chipset: Intel® B360, Memory: 4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory *Dual Channel Memory Architecture , Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI/DVI-D/D-Sub, ports , Supports AMD 2-Way CrossFireX™ Technology, 1 x PCIe 3.0/2.0 x16 (x16 mode), 1 x PCIe 3.0/2.0 x16 (max at x4 mode), 2 x PCIe 3.0/2.0 x1, 2 x PCI, 1 x M.2 Socket 3*2, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode), 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode), 6 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10, LAN: Realtek® RTL8111H, 1 x Gigabit LAN Controller(s), Back I/O ports: 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI-D. 1 x D-Sub, 1 x HDMI, 1 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 2 (teal blue)up to 10Gbps, 2 x USB 3.1 Gen 1 (blue) up to 5Gbps, 4 x USB 2.0, 3 x Audi
ASUS PRIME H370-A
Intel® Socket 1151 for 8th Generation Core™ Processors, Chipset: Intel® H370, Memory: 4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory *Dual Channel Memory Architecture, Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support: HDMI/DisplayPort/D-Sub ports, Supports AMD 2-Way CrossFireX™ Technology, 1 x PCIe 3.0/2.0 x16 (x16 mode), 1 x PCIe 3.0/2.0 x16 (max at x4 mode), 4 x PCIe 3.0/2.0 x1, 1 x M.2 Socket 3*2, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode), 1 x M.2 Socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode), 6 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10, LAN: Realtek® RTL8111H, 1 x Gigabit LAN Controller(s), Back I/O ports: 1 x PS/2 keyboard/mouse combo port(s), 1 x D-Sub, 1 x DisplayPort, 1 x HDMI, 1 x LAN (RJ45) port(s), 2 x USB 3.1 Gen 2 (teal blue)Type-A, 2 x USB 3.1 Gen 1 (blue), 2 x USB 2.0, 3 x Audio jack(s)
MB ASUS PRIME H370-PLUS
ASUS PRIME H370-PLUS
Intel® Socket 1151 for 8th Generation Core™ Processors
Chipset: Intel® H370
Memory: 4 x DIMM
Max. 64GB
DDR4 2666/2400/2133 MHz Non-ECC
Un-buffered Memory *Dual Channel Memory Architecture
Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support: HDMI/DisplayPort /D-Sub ports
Supports AMD 2-Way CrossFireX™ Technology
1 x PCIe 3.0/2.0 x16 (x16 mode)
1 x PCIe 3.0/2.0 x16 (max at x4 mode)
2 x PCIe 3.0/2.0 x1
2 x PCI
1 x M.2 Socket 3*2
with M Key
type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)
1 x M.2 Socket 3
with M key
type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)
6 x SATA 6Gb/s port(s)
gray
Support Raid 0
1
5
10
LAN: Realtek® RTL8111H
1 x Gigabit LAN Controller(s)
Back I/O ports: 1 x PS/2 keyboard/mouse combo port(s)
1 x D-Sub
1 x DisplayPort
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.1 Gen 2 (teal blue)Type-A
2 x USB 3.1 Gen 1 (blue)
2 x USB 2.0
3 x Audio jack(s)
